MIL-DTL-62337C(AT)
TABLE V. Linear cycling rates.
Total frequency
Frequency band
Sweep time in
Linear cycling
range (Hz)
(Hz)
minutes
rate (Hz/min)
(min-max-min)
2 - 500 or
2 to 5
3
2
5 - 500
5 to 22.5
6
5.8
As applicable
22.5 to 110
5
35
110 to 500
4
195
5 to 22.5
6
5.8
22.5 to 110
5
35
5 - 2000
110 to 500
4
195
500 to 900
3
267
900 to 2000
2
1100
ACCELERATION LEVELS: + g (PEAK)
(Hz)
FIGURE 3. Vibration test curve for equipment installed in ground vehicles.
15
